De-sta-co 802-U-RC Pneumatic Hold Down Toggle Clamp

Product Description

The DE-STA-CO 802-U-RC is a pneumatic hold down toggle clamp designed for workholding applications in industrial and manufacturing environments. It delivers an inner holding capacity of 200 pounds (890 N) and an outer clamping force of 235 pounds (1045 N), operating on compressed air up to 34 psi (2.20 bar). The clamp features a solid bar with a 102-degree opening arc and a 1/8 NPT air port. At 1.06 inches of height under bar, it suits low-profile fixturing setups. Installation and adjustment are typically performed by industrial maintenance technicians and tooling specialists.

This clamp is suited for horizontal mounting on jigs, fixtures, and production tooling where pneumatic actuation is preferred over manual operation. The closed bar end and solid bar style make it appropriate for repeatable, high-cycle clamping tasks on assembly lines, machining centers, and welding fixtures. It is compatible with round and T-slot sensor mounting configurations, supporting integration with automated sensing and process control systems. The included spindle assembly provides a complete, ready-to-install unit out of the box.

Key Features

• Inner holding capacity of 200 pounds (890 N) with outer clamping force of 235 pounds (1045 N)
• Operates at up to 34 psi (2.20 bar) via 1/8 NPT air port
• 102-degree bar opening for clear workpiece loading and unloading
• 1.06-inch height under bar for low-profile fixture integration
• Compatible with round and T-slot sensors for automated process feedback
• Includes spindle assembly for complete out-of-box installation
• Horizontal mounting orientation with 0.22-inch mounting holes spaced 0.50 inches (length) by 1.06 inches (width)

Compatibility

Compatible with round and T-slot sensor configurations as stated by the manufacturer. Designed as a direct-fit pneumatic hold down toggle clamp for horizontal-mount industrial fixturing applications requiring automated or remote actuation.

Installation Notes

Installation is typically performed by qualified tooling or maintenance technicians familiar with pneumatic workholding systems. Depressurize the air supply before connecting or disconnecting the 1/8 NPT port to avoid unintended clamp actuation. Verify that the shop air supply does not exceed the 34 psi maximum operating pressure before commissioning. Operating temperature range is 14 degrees F to 194 degrees F; do not use outside this range.
