De-sta-co 802-U-LC Pneumatic Hold Down Toggle Clamp 200 Lb

Product Description

The DE-STA-CO 802-U-LC is a pneumatic hold down toggle clamp designed to secure workpieces in fixtures, jigs, and production tooling. Actuated by compressed air through a 1/8 NPT port, it delivers an inner holding capacity of 200 pounds (890 N) and an outer clamping force of 1,045 N. The solid bar opens to 102 degrees, providing clear access to the workpiece during load and unload cycles. With a 1.26-inch cylinder bore and a height under bar of 1.06 inches, this clamp suits low-profile fixturing applications where vertical clearance is limited. A spindle assembly is included. Installation and setup are typically performed by tooling technicians, fixture builders, and manufacturing engineers.

The 802-U-LC is suited for horizontal mounting in production fixtures on manufacturing lines, welding stations, machining centers, and assembly tooling. The 102-degree bar opening allows operators to quickly place and remove parts without obstruction. Its pneumatic actuation makes it appropriate for automated or semi-automated clamping cycles where manual toggle clamping is impractical. The clamp operates across a temperature range of 14 degrees F to 194 degrees F, making it functional in both climate-controlled facilities and moderate industrial environments.

Key Features

• Pneumatic actuation via 1/8 NPT port for consistent, repeatable clamping force
• 200 lb (890 N) inner holding capacity with 1,045 N outer clamping force
• 102-degree bar opening for fast, unobstructed workpiece loading
• Solid closed-end bar style with 1.73-inch bar extension
• Compatible with round and T-slot sensor mounting for position detection
• Spindle assembly included for immediate installation readiness

Compatibility

Designed as an OEM-style pneumatic hold down toggle clamp for horizontal-mount fixturing applications. Compatible with sensors using round or T-slot mounting configurations. Air supply connection via standard 1/8 NPT port.

Installation Notes

Installation is typically performed by tooling or fixture technicians. Depressurize the air supply and lock out pneumatic energy sources before mounting or servicing this clamp. Secure the clamp to the fixture base through the four mounting holes using fasteners appropriate for the hole size of 0.22 inches. Do not exceed the maximum air pressure rating of 2.20 bar during operation.
