Danfoss 120H0237 DANFOSS SH300B4AAF Scroll Compressor 120H0237

Product Description

The Danfoss 120H0237 is a hermetic scroll compressor designed for air conditioning systems. It works with R410A refrigerant and has fixed speed capacity control. This compressor is suitable for power supplies of three-phase 380-415 volts at fifty hertz or 460 volts at sixty hertz.

• Compatible with R410A refrigerant
• Fixed speed design for reliable performance
• IP54 protection when installed with a cable gland

Product Highlights

The Danfoss 120H0237 offers robust performance in HVAC applications, ensuring efficient cooling in residential or commercial settings.

Product Information

Standard Information

• Brand: Danfoss
• MPN: 120H0237

Technical Specifications

• Model Number: SH300B4AAF
• Type: SH300-4
• Refrigerant: R410A
• Power Supply: 380-415/3/50 or 460/3/60 V/Ph/Hz
• Frequency: 50/60 Hz
• Nominal Voltage at 50Hz: 400 V
• Nominal Voltage at 60Hz: 460 V
• Phase: 3
• Capacity Control: Fixed speed
• Brazed Connections: Yes
• Oil Charge: 6.7 L
• IP Protection Class: IP54
• Motor Protection: Electronic module, 24 V AC
• Weight: 152.00 kg
• Max Pressure High Side: 45 bar
• Max Pressure Low Side: 30.2 bar
• Rotational Speed at 50Hz: 2900 rpm
• Rotational Speed at 60Hz: 3500 rpm
• Dimensions Height: 723 mm
• Dimensions Diameter: 333 mm
