Daikin CAPTA1818A4 1.5 Ton Coil R410A

Product Description

The DAIKIN CAPTA1818A4 1.5 Ton Coil R410A is an all-aluminum CAPT/CAPTA cased upflow/downflow cased coil with a factory-installed TXV, designed for split system air conditioners and heat pumps. It features aluminum tubing and corrugated aluminum fin coils. The unit has rust-resistant, high-temperature, thermoplastic drain pans and a cabinet painted nickel gray.

• Features internal factory installed thermal expansion valves (TXV) for cooling and heat pump applications
• Equipped with rust-resistant high-temperature thermoplastic drain pans with a low water retention design
• Includes an all-aluminum evaporator coil

Product Highlights

This Daikin coil is AHRI certified and ETL listed, with a 21-inch depth for easier attic access. It uses R-410A refrigerant and has a galvanized, leather grain-embossed finish.

Product Information

Standard Information

• Brand: DAIKIN
• Manufacturer Part Number: CAPTA1818A4

Technical Specifications

• Series: CAPTA
• Type: Cased, Upflow/Downflow, Indoor
• Nominal Capacity: 1.5 tons
• Liquid Line Size: 3/8 inch
• Suction Line Size: 3/4 inch
• Tubing Material: Aluminum
• Fin Material: Aluminum
• Condensate Drain Connections: 3/4 inch FNPT
• Refrigerant Type: R-410A
• Cabinet Depth: 21 inch
• Cabinet Height: 18 inch
• Finish/Color: Galvanized, Leather Grain-Embossed
• Cabinet Width: 14 inch
• Orientation: Vertical
• For Use With: R-410A Refrigerant, Heat Pump
• Applications: For Cooling and Heat Pump Applications
• Standards/Approvals: AHRI Certified, ETL Listed
• Model code: CAPTA1818A4
