Cutler-Hammer GHB3060 Circuit Breaker 60A 3P

Product Description

The Cutler-Hammer GHB3060 is a molded case circuit breaker with a rating of sixty amps and three poles. This circuit breaker is designed for various electrical applications, ensuring reliable protection for branch circuits.

• Compact size for easy installation
• Rated for 480Y/277 Vac and 125/250 Vdc
• Fixed thermal and magnetic trip types

Product Highlights

This circuit breaker is ideal for panelboards, switchboards, and motor control centers. It is engineered for dependable circuit protection in industrial and commercial environments.

Product Information

Standard Information

• Brand: Cutler-Hammer
• MPN: GHB3060

Technical Specifications

• Type: Molded case circuit breaker
• Amperage Rating: 60A
• Interrupt Rating: 65 kAIC at 240 Vac, 14 kAIC at 480Y/277 Vac
• Number Of Poles: Three-pole
• Voltage Rating: 480Y/277 Vac, 125/250 Vdc
• Trip Type: Fixed thermal, fixed magnetic
• Circuit Breaker Frame Type: Complete breaker
• Frame Size: G-frame
• Series: Series C
• Dimensions: 4 inches height, 2.63 inches length, 3 inches width
• Weight: 1.7 pounds
• Frequency Rating: 50/60 Hz
