Cutler-Hammer GHB3020 Circuit Breaker 20A 3P 14 kA

Product Description

The Cutler-Hammer GHB3020 is a molded case thermal magnetic circuit breaker designed for reliable circuit protection in electrical applications. This breaker is suitable for use in panelboards, motor control centers, and other distribution setups.

• Amperage Rating: 20A
• Three-pole operation for enhanced circuit management
• Interrupt rating of 65 kAIC for 240 Vac and 14 kAIC for 480Y/277 Vac

Product Highlights

Designed for reliable performance, the Cutler-Hammer GHB3020 ensures protection against overloads and short circuits, making it essential for any electrical distribution system.

Product Information

Standard Information

• Manufacturer: Cutler-Hammer
• Type: Molded case circuit breaker

Technical Specifications

• Height: 4 inches
• Length: 2.63 inches
• Width: 3 inches
• Weight: 1.75 lbs
• Trip Type: Fixed thermal, fixed magnetic
• Voltage Rating: 480Y/277 Vac, 125/250 Vdc
• Number of Poles: Three-pole
• Frequency Rating: 50/60 Hz
• Series: Series C
• Frame Size: G-frame
• Interrupt Rating: 65 kAIC at 240 Vac, 14 kAIC at 480Y/277 Vac
