Cpc Colder Products MCD2202 Coupling Insert 1/8 in

Product Description

The CPC COLDER PRODUCTS MCD2202 is a push-to-connect coupling insert designed for quick, tool-free tube connections in fluid-handling systems. Constructed from chrome-plated brass, this fitting accepts 1/8 inch inside diameter tubing and is rated to 250 psi maximum working pressure. The valved, free-floating design allows the insert to self-seal when disconnected, preventing fluid loss during service or line changes. Operating temperature range spans -40 degrees F to 180 degrees F, making it suitable for a wide range of ambient and fluid conditions. Plumbers, fluid system technicians, and industrial maintenance professionals commonly install this type of fitting in general-purpose pneumatic and liquid circuits.

The MCD2202 is intended for general-purpose fluid and pneumatic applications where fast, reliable tubing connections are required. The push-to-connect design eliminates the need for threaded assembly tools at the connection point, reducing installation time in tight spaces or high-volume plumbing tasks. The chrome-plated brass body resists corrosion in typical indoor service environments. The nitrile O-ring provides a compatible seal for a broad range of fluids, including water, air, and many common hydraulic fluids used in light industrial and commercial settings.

Key Features

• Push-to-connect design for tool-free tubing installation and removal
• Valved and free-floating construction allows self-sealing upon disconnect
• Chrome-plated brass body for corrosion resistance
• Rated to 250 psi maximum working pressure
• Operating range of -40 degrees F to 180 degrees F
• Nitrile O-ring for broad fluid compatibility

Compatibility

Designed as a general-purpose push-to-connect coupling insert suitable for 1/8 inch ID tubing in pneumatic and fluid-handling systems across light industrial and commercial applications.

Installation Notes

Installation is performed by qualified plumbing or fluid system technicians. Depressurize and isolate the line before installing or removing the fitting. Verify that tubing outside diameter and wall thickness are compatible with the 1/8 inch ID insert specification before seating the connection. Inspect the nitrile O-ring for damage prior to installation and ensure tubing is cut cleanly and squarely for a leak-free seal.
