Coxreels DMPL-4100 Dual Product Spring Driven Hose Reel

Product Description

The COXREELS DMPL-4100 is a DP Series dual product delivery spring driven hose reel designed for applications requiring simultaneous delivery through two separate hose lines. It features two external swivel inlets and two outlets, making it well suited for low and medium pressure systems where large volume delivery is needed. The unit is built around a sturdy box-style steel frame with heavy duty cross supports at all four corners. Weighing 138 pounds and measuring 33.5 inches long by 22 inches wide by 29 inches tall, it is sized for demanding commercial and industrial service environments. Licensed technicians and trade professionals working in fluid delivery, lubrication, or multi-product dispensing applications are the primary installers.

The DMPL-4100 is used in settings where two separate fluid products must be delivered from a single reel station. Typical applications include automotive service shops, fleet maintenance facilities, industrial lubrication systems, and similar environments where dual hose operation reduces equipment footprint without sacrificing flow capacity. The reel accommodates hose with a 1/2 inch inner diameter and 15/16 inch outer diameter up to 100 feet in length, supporting large volume transfer at low to medium operating pressures. Its spring driven retraction keeps hose organized and reduces trip hazards on the shop floor.

Key Features

• Two machined solid brass 90-degree full-flow NPT swivel inlets allow seal maintenance and hose installation without removing the reel from its mount
• Lubricated enclosed cartridge-style motor is removable for safe, straightforward maintenance
• Heavy duty CNC robotically spun and ribbed discs with rolled edges provide strength, durability, and hose protection
• Reinforced steel box-style frame with dual inlets and outlets handles demanding dual hose applications
• Exclusive low profile outlet riser and open drum slot design produces a flat, non-crimping hose wrap
• CPC powder coat finish resists chips and rust; stainless steel pinch-proof rollers, stainless steel pawl spring, and self-lubricated flange bearings included

Compatibility

Designed for use with 1/2 inch inner diameter hose up to 100 feet in length at low to medium operating pressures in dual product delivery systems.

Installation Notes

Installation should be performed by a qualified technician familiar with fluid handling systems and applicable local codes. Shut off all fluid supply lines and depressurize the system completely before mounting or servicing the reel. Ensure the mounting surface and fasteners are rated to support the loaded weight of the reel and hose. Verify all swivel inlet connections are sealed and leak-free before returning the system to service.

Technical Specifications

• Hose Inner Diameter: 1/2 inch
• Hose Outer Diameter: 15/16 inch
• Hose Capacity: 100 feet
• Drive Type: Spring driven
Inlets: Two external NPT swivel inlets
• Outlets: Two
• Frame Material: Steel
• Finish: CPC powder coat
• Length: 33.5 inches
• Width: 22 inches
• Height: 29 inches
• Weight: 138 pounds
• UPC: 674255814325

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: DMPL-4100
