Coxreels 1275-6-50-EA Dual Hose Reel 1 in Id 50 Ft

Product Description

The COXREELS 1275-6-50-EA is a heavy-duty dual hose reel from the 1275 Series, engineered for large-capacity industrial and commercial applications. It accepts hose with a 1-inch ID and 1-7/16-inch OD, with a 50-foot hose capacity. The reel ships with a 115-volt AC, 1/2 HP reversible AC rectified motor for powered retrieval, and can also be operated by hand crank. Two swivel inlets and two low-profile outlet risers work together to deliver a non-crimping, flat, smooth hose wrap across the open drum slot. Licensed HVAC, plumbing, and industrial service technicians install this unit in high-demand service bays, wash-down stations, and fluid transfer setups.

The 1275-6-50-EA fits large-capacity service environments where dual-line delivery is required. The dual plumbing configuration makes it well-suited for commercial lubrication systems, industrial wash-down stations, and similar high-volume fluid handling installations. The open drum slot design accommodates large-diameter hose without kinking or flattening, making it appropriate for both continuous and intermittent service cycles where hose integrity is critical.

Key Features

• Dual plumbing with two machined solid-brass 90-degree full-flow NPT swivels for simple seal maintenance and fast hose installation without removing the reel from its mount
• Two low-profile outlet risers combined with an open drum slot deliver a non-crimping, flat, smooth hose wrap
• One-piece all-CNC robotically welded 12-gauge steel A-frame base provides superior reel rigidity and strength without bolted joints
• Heavy-duty CNC robotically spun and ribbed discs with rolled edges for greater strength, durability, hose protection, and operator safety
• Permanently lubricated, self-aligning pillow block bearings for smooth rotation and long service life
• Chip-resistant, rust-inhibiting CPC powder coat finish for extended service life in demanding environments
• 115-volt AC, 1/2 HP reversible AC rectified motor included for powered retrieval

Compatibility

Designed as an OEM-style large-capacity dual hose reel for industrial and commercial fluid handling systems requiring 1-inch ID hose with up to 50-foot runs.

Installation Notes

Installation is typically performed by qualified industrial or mechanical service technicians. Power down or disconnect all electrical and fluid supply lines before mounting or servicing the reel. The mounting pattern is located in the steel base for straightforward installation and detachment. Verify that the supply voltage matches the motor rating of 115 volts AC before energizing the unit.

Technical Specifications

• Hose ID: 1 inch
• Hose OD: 1-7/16 inches
• Hose Capacity: 50 feet
• Motor Voltage: 115 volts AC
• Motor Output: 1/2 HP
• Motor Type: Reversible AC rectified
• Frame Material: 12-gauge steel, CNC robotically welded
• Finish: CPC powder coat
• Length: 31 inches
• Width: 20 inches
• Height: 23 inches
• Weight: 86 pounds
• UPC: 674255839076

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1275-6-50-EA
