Coxreels 1125P-4-12 Pure Flow Hose Reel 1/2 in 200 Ft

Product Description

The COXREELS 1125P-4-12 is a Pure Flow series spring-rewind hose reel engineered for clean-fluid applications including breathing air and potable water. The reel features an all-stainless-steel air and fluid path, a stainless-steel 90-degree full-flow NPT swivel inlet, and a non-toxic food-quality grease-packed swivel to prevent fluid contamination. Designed for 1/2-inch ID hose with a 7/8-inch OD and rated for up to 200 feet of hose, it weighs 39 pounds and measures 25.5 inches long by 18 inches wide by 20 inches tall. HVAC service techs, plumbers, and safety professionals install this reel where sanitary, uncontaminated fluid transfer is a code or regulatory requirement.

The 1125P-4-12 suits residential and commercial installations requiring safe storage and deployment of respiratory air hose lines for low- or high-pressure breathing systems, potable water hose lines for drinking water service, and any application demanding a sanitized, non-contaminated fluid path. The spring-rewind retraction mechanism keeps hose tidy and reduces trip hazards on busy job sites. The CPC powder-coat finish resists chipping and rust, making this reel suitable for indoor mechanical rooms as well as covered outdoor service areas.

Key Features

• All-stainless-steel air and fluid path with stainless-steel 90-degree full-flow NPT swivel inlet and food-quality grease for contamination-free transfer
• CNC robotically spun and ribbed heavy-duty discs with rolled edges for hose protection and operator safety
• Exclusive low-profile outlet riser and open drum slot design delivers a non-crimping, flat smooth hose wrap
• One-piece CNC robotically welded 12-gauge steel A-frame base with integrated mounting pattern for secure installation and easy detachment
• Adjustable tension brake prevents free-wheeling; direct hand crank available for manual retraction
• Long-lasting CPC powder-coat finish resists chips and rust in demanding service environments

Compatibility

Designed for use with 1/2-inch ID hose in breathing air, potable water, and other clean-fluid hose reel applications requiring a stainless-steel fluid path and sanitary swivel construction.

Installation Notes

Installation should be performed by a licensed plumber, HVAC technician, or qualified safety equipment professional familiar with the applicable fluid system requirements. Shut off and depressurize the fluid or air supply line completely before connecting or disconnecting the reel. Mounting hardware must be appropriate for the substrate and capable of supporting the loaded weight of the reel and hose. Verify all NPT thread connections are sealed with a compatible, food-safe thread sealant when used in potable water or breathing-air service.

Technical Specifications

• Hose ID: 1/2 inch
• Hose OD: 7/8 inch
• Hose Capacity: 200 feet
• Retraction Type: Spring rewind
• Swivel Material: Stainless steel
• Frame Construction: 12-gauge CNC welded steel A-frame
• Finish: CPC powder coat
• Length: 25.5 inches
• Width: 18 inches
• Height: 20 inches
• Weight: 39 pounds
• UPC: 674255829145

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1125P-4-12
