Copeland ZR21K5E-TF5-800 Air Conditioning Compressor

Product Description

The COPELAND ZR21K5E-TF5-800 is a hermetic scroll compressor suited for air conditioning systems. This unit works effectively with R22 and R407C refrigerants and operates on a voltage supply of two hundred to two hundred thirty volts, three-phase, sixty hertz. It features a three-fourths inch suction connection and a half-inch discharge connection, both designed to be sweat-type. A capacitor is required for operation, though it is not included. The compressor uses polyol ester oil for lubrication, ensuring efficient performance.

• Designed for air conditioning systems
• Compatible with R22 and R407C refrigerants
• Features sweat-type suction and discharge connections

Product Highlights

This compressor delivers reliable cooling performance and is perfect for various air conditioning applications.

Product Information

Standard Information

• Brand: Copeland
• MPN: ZR21K5E-TF5-800

Technical Specifications

• Application: A/C
• Refrigerant: R22, R407C
• Voltage: 200/230V
• Phase: 3
• Frequency: 60/50 Hz
• Capacity (BTUH): 21000
• Horsepower: 1.8
• Oil Type: Polyol Ester
• Oil Recharge (Oz.): 19
• Suction Line Connection Size: 3/4
• Discharge Line Connection Size: 1/2
• Connection Type: Sweat
• Mounting Length: 7.5
• Mounting Width: 7.5
• Height: 15.859
• Length: 9.5
• Width: 9.5
• Rated Load Amps: 8.6
• Displacement (CFH): 214.8615
• Displacement (In³/Rev): 1.768
• Compressor Protection: Hermetic
• Standards: UL-CSA-MEA
• Cooling Capacity: 27500 BTUH
• Current: 8.6A
• Electrical Connection Type: Molded Plug
