CONTROL TECHNIQUES S100-03D13 Commander S AC Drive

Product Description

The CONTROL TECHNIQUES S100-03D13 is a micro AC drive from the Commander S series, specifically designed for efficient motor control. It operates on a single-phase 230VAC input and converts it to a three-phase 230VAC output. This drive includes integrated electromagnetic compatibility (EMC) filters that meet the IEC 61800-3 category C3 standards. It can handle both normal and heavy-duty applications with a maximum continuous output current of 10.6A, which is equivalent to three horsepower.

• Single-phase 230VAC input and three-phase output.
• Maximum continuous output current of 10.6A (3HP).
• Integrated EMC filters compliant with IEC 61800-3, category C3.

Product Highlights

Designed for ease of installation and versatile application suitability, this drive supports a variety of motor control methods and stopping modes for optimal performance.

Product Information

Standard Information

• Brand: CONTROL TECHNIQUES
• MPN: S100-03D13

Technical Specifications

• Input Voltage: 230VAC
• Output Voltage: 230VAC
• Output Current: 10.6A
• Horsepower: 3HP
• Power Range: 0.25 to 5 hp / 0.18 to 4 kW
• Input Frequency: 50/60 Hz
• Output Frequency: 0 to 300 Hz
• Duty Rating: Heavy Duty
• Motor Control: Linear V to F, Square V to F, Resistance, Compensation
• Stopping Modes: Coast, Ramp, DC Injection Braking
• Communication Ports: RJ45 for Modbus RTU, NFC interface
• IP Rating: IP20
• Operating Temperature: -10°C to 40°C without de-rate, up to 60°C with de-rate
• Storage Temperature: -40°C to 60°C
• Certifications: CE, UKCA, cULus, C-Tick, EAC, KC
• Switching Frequency: 4 kHz and 12 kHz
