Control Techniques S100-03413 AC Drive

Product Description

The Control Techniques S100-03413 is a micro AC drive designed for energy-efficient motor control. It accepts a 460Vac 3-Phase input and provides a 460Vac 3-Phase output, making it suitable for basic applications. This AC drive features integrated EMC filters that meet IEC 61800-3, category C3, ensuring compatibility with various setups. The device can be monitored and configured using the MARSHAL App via NFC technology.

• Input: 460Vac 3-Phase
• Output: 460Vac 3-Phase
• Features NFC connectivity for app-based monitoring

Product Highlights

Ideal for motor control and energy savings in simple applications.

Product Information

Standard Information

• Brand: Control Techniques
• MPN: S100-03413

Technical Specifications

• Input Voltage: 1 Phase AC 115 & 230 V, 3 Phase AC 230 & 460 V
• Input Frequency: 50/60 Hz
• Output Frequency: 0 to 300 Hz
• Output Current: 7.2A
• Power Range: 0.25 to 5 hp / 0.18 to 4 kW
• Horse Power: 3HP
• Duty Rating: Heavy Duty
• Switching Frequency: 4 kHz and 12 kHz
• Motor Control: Linear V to F, Square V to F, Resistance, Compensation
• Stopping Modes: Coast, Ramp, Ramp & DC Injection Braking
• Communications: RJ45 for Modbus RTU, NFC for app interface
• Enclosure Rating: IP20
• Mounting Type: DIN rail mount
• Operating Temperature: -10°C to 60°C
• Certifications: CE, UKCA, cULus, EAC, KC
• EMC Compliance: C3 internal EMC filters
