Continental Contitech 20042166 B Section V-belt B210

Product Description

The CONTINENTAL CONTITECH 20042166 is a Section B V-belt designed for industrial and HVAC drive applications where a reliable, heat- and cold-resistant power transmission belt is required. Built with Wingprene rubber-impregnated fabric construction, this belt delivers strong resistance to heat, oil, and flexing fatigue. It carries an outside length of 213 inches and an internal length of 211.80 inches, making it suited for large-diameter drive systems. Rated for operation from -40 degrees C to 140 degrees C, it handles both low-temperature startup conditions and sustained high-temperature environments. Licensed HVAC technicians, industrial mechanics, and facilities maintenance professionals are the primary installers.

This belt is used in commercial and industrial drive systems where Section B V-belt geometry is specified, including fan drives, blower assemblies, pump drives, and compressor applications. The HY-T Matchmaker profile designation indicates it is engineered for matched-set compatibility in multi-belt drive configurations, ensuring consistent load sharing across all belt positions. It is sold as a single belt, making it suitable for both single-belt drives and as a matched replacement in existing multi-belt setups.

Key Features

• Section B V-belt profile for standard B-section sheaves and pulleys
• 213-inch outside length, 211.80-inch internal length for large drive configurations
• Wingprene rubber-impregnated fabric construction resists heat, oil, and flex fatigue
• Wide operating temperature range: -40 degrees C to 140 degrees C
• HY-T Matchmaker style for use in matched multi-belt drive sets
• Sold individually with a minimum order quantity of one

Compatibility

Designed as a replacement for B210-designation Section B V-belts in industrial, commercial HVAC, and mechanical drive applications using standard B-section sheaves and pulleys.

Installation Notes

Installation should be performed by a qualified mechanic or licensed HVAC technician. Disconnect and lock out all power to the drive system before removing the old belt or installing the new one. Never pry a V-belt over sheave flanges with tools that could nick or cut the belt; always relieve tension through the motor adjustment mechanism. Verify sheave alignment and inspect sheave grooves for wear before installing the replacement belt.
