Continental Contitech 20042152 B Section V-belt 161 in B158

Product Description

The CONTINENTAL CONTITECH 20042152 is a Section B classical V-belt designed for power transmission in industrial and commercial drive applications. Built with Wingprene rubber-impregnated fabric construction, this belt delivers reliable flex strength and resistance to heat, oil, and environmental exposure. It carries a 161-inch outside length with a 159.80-inch internal length and is cross-referenced as belt number B158. The HY-T Matchmaker design allows this belt to be matched with other belts in multi-belt drive configurations, maintaining consistent tension across paired or ganged sheave arrangements. Licensed HVAC technicians, mechanical contractors, and industrial maintenance professionals are the primary installers.

This V-belt is suited for use in belt-driven HVAC systems, fans, blowers, compressors, pumps, and general industrial machinery that use standard B-section sheaves. The B-section profile fits industry-standard grooved pulleys and is widely applied in rooftop units, air handling units, and belt-driven centrifugal fans. The wide operating temperature range of -40 degrees F to 284 degrees F makes it appropriate for both refrigerated environments and high-heat mechanical rooms. The HY-T Matchmaker designation supports use in matched-set multi-belt drives where consistent belt length and profile are critical.

Key Features

• Section B profile fits standard B-groove sheaves used in HVAC and industrial drive applications
• 161-inch outside length (B158) for large-diameter or long-center-distance drive configurations
• Wingprene rubber-impregnated fabric construction for oil resistance and extended flex life
• HY-T Matchmaker design supports matched-set installation on multi-belt drives
• Rated for operating temperatures from -40 degrees F to 284 degrees F

Compatibility

Designed as a standard B-section V-belt replacement cross-referenced as belt number B158, compatible with any B-section sheave or pulley system requiring a 161-inch outside length drive belt.

Installation Notes

Installation is typically performed by licensed HVAC technicians or mechanical maintenance technicians. Always de-energize and lock out the drive motor before removing or installing belts. Proper belt tension should be set according to the equipment manufacturer specifications using a belt tension gauge. Never use tools to force the belt over sheave flanges, as this can damage the belt cords and reduce service life.
