Continental Contitech 20042054 V-belt Section B 39in B36

Product Description

The CONTINENTAL CONTITECH 20042054 is a Section B V-belt designed for power transmission applications in industrial and commercial mechanical systems. Constructed from Wingprene rubber-impregnated fabric, this belt delivers reliable torque transfer across a range of operating conditions. It carries a B36 belt designation, with an outside length of 39.0 inches and an internal length of 37.80 inches. The HY-T Matchmaker style profile is engineered for consistent performance in matched-set or single-belt drive configurations. Rated for operating temperatures from -40 degrees C to 140 degrees C, this belt handles both cold-start environments and high-heat mechanical enclosures. It is installed by HVAC technicians, millwrights, and mechanical contractors on belt-driven fans, blowers, pumps, and compressors.

This V-belt is suited for residential and light commercial HVAC equipment, industrial machinery, agricultural drives, and general-purpose belt-drive systems where a Section B profile is specified. Common applications include blower drives in air handling units, belt-driven pumps, and motor-to-load power transmission setups requiring a 39.0-inch outside length belt. The B36 designation allows direct cross-reference when replacing OEM-specified belts on equipment calling for a standard B-section drive belt.

Key Features

• Section B profile with 39.0-inch outside length and 37.80-inch internal length
• Wingprene rubber-impregnated fabric construction for durability and heat resistance
• HY-T Matchmaker style suitable for matched-set multi-belt drive applications
• Wide operating temperature range: -40 degrees C minimum to 140 degrees C maximum
• B36 belt number for straightforward OEM and aftermarket cross-reference
• Lightweight at 0.4 pounds for easy handling during installation

Compatibility

Designed as a direct replacement for Section B V-belt applications specifying a B36 belt designation with a 39.0-inch outside length. Suitable for any drive system engineered to accept a standard B-section V-belt profile.

Installation Notes

V-belt replacement is typically performed by HVAC technicians, millwrights, or mechanical maintenance personnel. Always de-energize and lock out the drive motor before removing or installing the belt. Adjust drive sheave alignment and belt tension according to the equipment manufacturer's specifications before returning the system to service. Do not force the belt over sheave flanges using tools that could damage the belt fabric or cord.
