Conbraco 70-109-01A 2-1/2 Brz Std Ball Valve

Product Description

The CONBRACO 70-109-01A is a 2-Piece In-Line Standard Ball Valve, part of the Series 70-100. It features a 2-1/2 IN nominal size and FNPT connection type. The valve is constructed with a bronze body and a brass stem and ball. It is suitable for pressure ratings of 600 PSI (CWP) and 150 PSI (SWP).

• Features premium materials and heavy-duty construction.
• Equipped with an adjustable stem packing gland.
• Includes a blowout-proof stem design.

Product Highlights

This ball valve is 100% factory tested and suitable for general purpose use with a wide range of options.

Product Information

Standard Information

• Brand: CONBRACO
• Manufacturer Part Number: 70-109-01A
• Country of Origin: Domestic

Technical Specifications

• Series/Model: Series 70-100
• Nominal Size: 2-1/2 IN
• Connection Type: FNPT
• Pressure Rating: 600 PSI (CWP), 150 PSI (SWP)
• Temperature Rating: -20 To 450 DEG F
• Opening: 2 IN
• Body Material: Bronze
• Operator Type: Lever Handle
• Handle Material: Steel With Vinyl Grip
• Stem Material: Brass
• Trim Material: Brass Ball
• Packing Material: MPTFE Stem
• Seat Material: RPTFE
• Seal Material: PTFE
• Body Material Standard: ASTM B584
• Ball And Stem Material Standard: ASTM B16
• Body Material Specification: UNS C84400
• Finish/Color: Chrome Plated Ball, Zinc Plated Handle
• Industry Standards: MSS-SP-110 Compliant, CSA B51, CRN: OC10908.5C
• Width: 6-1/4 IN
• Lead Free: No
• Flow Co-Efficient (Cv): 190
• Media: Gas, Water
• Orifice Size: 2 in
• Port Type: Standard
• Ball Material: Chrome Plated Brass
• Softgoods Material: RPTFE/MPTFE
