Color-Keyed 54810 Connector Splice 2/0 AWG Copper 45 2.13 in

Product Description

Color-Keyed 54810 is a 2-Way Long Barrel Splice Connector designed for use with 2/0 AWG copper conductors. This splice connector ensures reliability and efficiency in electrical connections. The product features a unique color-coding system to help technicians match connectors to the right installation tools.

• Two-way connection for high pullout values
• Color-coded for easy installation
• Rated for up to 35 kV

Product Highlights

This connector provides a low-resistance connection that is easy to insulate and maintain. It is suitable for applications requiring compliance with standards up to 600 VAC and can accommodate a range of conductor sizes.

Product Information

Standard Information

• Brand: Color-Keyed
• Manufacturer: ABB - Installation Products

Technical Specifications

• Catalog Number: 54810
• Die Code: 45
• Voltage Rating: 600 VAC
• Conductor Size: 2/0 AWG
• Material: Copper
• Finish: Tin Plated
• Outside Diameter: 0.59 in
• Length: 2.13 in
