Color-Keyed 256-30695-1158PH Compression Lug 2-Hole 6 AWG

Product Description

The Color-Keyed 256-30695-1158PH is a compression lug designed for secure electrical connections. It features a two-hole design for easy installation with a 3/8 inch stud. This compression lug is ideal for use with six AWG copper conductors, ensuring high conductivity and reliability.

• Two-hole design for installation ease
• High conductivity wrought copper construction
• Tin plated for corrosion resistance

Product Highlights

The Color-Keyed Compression Lug incorporates a peep hole for secure crimping and is optimized for use with the Color-Keyed compression system.

Product Information

Standard Information

• Brand: Color-Keyed
• Manufacturer: ABB - Installation Products

Technical Specifications

• Type: 2-Hole Non-Insulated
• Color: Blue
• Die Code: 24
• Stud Size: 3/8 inch
• Conductor Size: 6 AWG
• Material: Copper
• Barrel Type: Long
• Voltage Rating: 35 kV
• Specifications: 1 inch Stud Hole Spacing, Tin Plated
