Climax Metal Products C600E-100 Shaft Locking Device

Product Description

The CLIMAX METAL PRODUCTS C600E-100 is a shaft locking device designed to secure rotating components to shafts in industrial mechanical assemblies. With a 1-inch bore diameter and a 66mm outer diameter, this locking device uses a 7-screw configuration to develop an axial load capacity of 14,976 pounds and a maximum torque rating of 624 ft/lb. The M6 thread size and an overall width of 2.598 inches make it a compact yet high-load solution for precision shaft retention applications. It is typically installed by industrial maintenance technicians and millwrights during machine assembly or component replacement.

This shaft locking device suits industrial machinery requiring reliable, high-torque shaft retention without keyways or set screws. The 1-inch bore fits standard inch-series shafts, while the 66mm OD accommodates common hub and housing configurations. The 7-screw clamping design distributes clamp load evenly around the shaft, supporting demanding rotational applications in motors, conveyors, gearboxes, and similar equipment. The thrust ring width of 1.496 inches provides a stable bearing surface for axial load transfer.

Key Features

• 1-inch bore diameter fits standard inch-series shafts
• 66mm outer diameter for compatibility with common hub and housing bores
• 7-screw clamping design for even load distribution and high retention force
• 14,976 lb axial load capacity for demanding industrial applications
• 624 ft/lb maximum torque rating
• M6 thread size with 2.598-inch overall width for compact installation

Compatibility

Designed as an OEM-style replacement or direct-fit shaft locking device for industrial machinery with 1-inch bore shafts and hub or housing configurations accommodating a 66mm outer diameter.

Installation Notes

Installation and removal should be performed by a qualified millwright or industrial maintenance technician. Ensure all machinery is de-energized and locked out per OSHA lockout/tagout procedures before beginning work. Clean shaft and bore surfaces thoroughly before seating the locking device to ensure full clamping contact. Tighten screws in a star pattern to the fastener manufacturer's specified torque to achieve uniform clamp load distribution.
