ClimateMaster AFCG2B1 Brass Flow Controller

Product Description

The ClimateMaster AFCG2B1 is a flow controller known for its brass construction. This unit features a brass body and spool with NBR seals and a stainless steel retaining ring. It includes a full-port, three-way, four-position valve for flushing and isolation or service purposes. The controller also utilizes CFC-free polyurethane foam and high-impact polystyrene, ensuring durable performance.

• Brass body and spool construction
• One full-port, three-way, four-position valve included
• Utilizes CFC-free polyurethane foam

Product Highlights

The ClimateMaster AFCG2B1 serves efficiently in various plumbing and HVAC applications, enhancing fluid control with reliable sealing and operational integrity.

Product Information

Standard Information

• Manufacturer: ClimateMaster
• Part Number: AFCG2B1
• Product Code: AFCG2B1

Technical Specifications

• Dimensions: seven point six three inches x ten point one nine inches x thirteen point two five inches
• Amps: 1.07 at 230V
• Capacitor: 2.5 µf/380V
• Nominal HP: one over six
• Pump: UP26-99 (two pumps)
• Pump Housing: Cast iron
• Voltage: 208-230V 60 Hz 1ph
• Watts: 245 at 230V
