Cleaver Brooks 833-02714-000 Uv Flame Scanner Module

Product Description

The CLEAVER BROOKS 833-02714-000 is a UV flame scanner module display designed to detect ultraviolet radiation emitted by a burner flame in boiler systems. The unit continuously monitors flame presence and transmits a signal to the burner control system for safety verification. When flame is lost or fails to establish, the scanner triggers a lockout condition, preventing unsafe operation. Built for demanding commercial and industrial environments, this component supports consistent performance across high-temperature conditions and frequent operating cycles. Licensed boiler technicians and combustion service specialists are the primary installers and servicers of this device.

This UV flame scanner module is intended for use with CLEAVER BROOKS boiler and burner systems in commercial and industrial applications. It fits into the optical flame supervision circuit of the burner management system, where reliable flame detection is a code-required safety function. Typical installation scenarios include firetube and watertube boiler plants, process steam systems, and large commercial heating systems where continuous burner supervision is mandated by insurance and regulatory standards.

Key Features

• Detects ultraviolet radiation emitted by burner flame for positive flame confirmation
• Sends continuous flame-presence signal to the burner management control system
• Triggers safety lockout when flame signal is lost or absent at startup
• Engineered for high-temperature boiler room environments and frequent cycle duty
• Module display format supports visual status indication during commissioning and service

Compatibility

Designed as an OEM-style replacement UV flame scanner module for CLEAVER BROOKS commercial and industrial boiler burner management systems.

Installation Notes

Installation and replacement of flame scanner components should be performed by a licensed boiler technician or qualified combustion service professional. Before servicing, shut down the burner, close the main fuel supply valve, and de-energize the burner control panel in accordance with the equipment lockout and tagout procedure. Verify scanner alignment with the optical sighting port per the equipment manufacturer guidelines before returning the system to service. Flame scanner replacement on commercial boilers may be subject to local boiler codes and insurance carrier inspection requirements.

Technical Specifications

• Detection Type: Ultraviolet (UV) flame detection
• Application: Boiler burner flame supervision

Standard Information

• Brand: CLEAVER BROOKS
• Manufacturer Part Number: 833-02714-000
