Chicago Faucets E80-A11A-16ABCPT E-Tronic 80 Series 0.5 GPM

Product Description

The CHICAGO FAUCETS E80-A11A-16ABCPT E-Tronic 80 Series is an advanced electronic commercial faucet with touchless sensor operation. It features a vandal-proof design and delivers reliable hands-free operation. Built with ECAST brass construction for low lead content, it meets rigorous compliance standards and is compatible with the Commander handheld programming unit for customizable settings.

• Easy install, monitoring, and maintenance in a commercial sensor faucet
• Durable, cast brass construction
• Pressure compensating Econo-Flo non-aerating spray outlet releases water at 0.5 GPM

Product Highlights

This touchless electronic faucet is designed for commercial lavatory applications where hygiene, durability, and water efficiency are essential.

Product Information

Standard Information

• Brand: CHICAGO FAUCETS
• Manufacturer Part Number: E80-A11A-16ABCPT

Technical Specifications

• Pressure compensating Econo-Flo non-aerating spray outlet: 0.5 GPM (243.145.AB.1)
• E-Tronic 80 module with Bluetooth communication: 244.458.00.1T
• Temperature Control: Includes optional user-adjustable temperature control. Pre-assembled with concealed internal temperature control mixer.
• Mounting: Single-hole
• Run Time: 10 second run time with hand presence. Safety auto-timeout feature will shut the water off after 10 seconds. Reactivate faucet by removing hands from the sensor for at least 1 second.
• Power: Includes 6-volt lithium CRP2 battery
• Bluetooth: Built-in Bluetooth technology allows for easy adjustments and mode changes using a smartphone or tablet with the Chicago Faucets CF Connect App.
• Supply: Dual supply with concealed internal mixer; flexible supply hoses included
• Finish: Polished chrome
• Package Quantity: 1
• Spout Length: 6 7/8 Inches
• Faucet Width: 2 1/4 Inches
• Faucet Height: 6 1/8 Inches
• Battery Type: 6V
• Faucet Centers: Single
• Features: ADA Compliant, Automatic Shutoff, Bluetooth, Hands Free, Motion Sensor
• Flow Rate: 0.5 GPM
• Installation Type: Deck Mounted
• Material: Brass
• Mounting Holes Required: 1 Mounting Hole
• Mounting Style: Deck Mounted
• Power Type: Battery
• Pressure Rating: 20 - 125 PSI
• Spout Clearance: 4 7/8 Inches
• Spout Type: Cast
• Temperature Rating: 48 - 180 Degrees F
• Type: Sensor
• Water Inlet Size: 3/8 Inches
• Operating Temperature: 180 F max.
• Pressure: 20 psi to 125 psi
• Manufacturer Item Number: E80-A11A-16ABCPT
• UPC: 611943164805
• Model Name: E-Tronic
