Central Components 413061 Central Components CYBT-413061-02 AIROC Bluetooth Module

Product Description

The Central Components CYBT-413061-02 is an AIROC Bluetooth module featuring the CYW20721 base silicon. This module enables Bluetooth Classic and Bluetooth Low Energy (BLE) communication.

• Supports Bluetooth Classic and Bluetooth LE
• Integrated Arm Cortex-M4 CPU core
• Operating temperature range of negative thirty degrees Celsius to eighty-five degrees Celsius

Product Highlights

This module combines a high-performance CPU with various communication interfaces, making it suitable for diverse applications.

Product Information

Standard Information

• Manufacturer Part Number: 413061
• Family: AIROC Bluetooth Modules

Technical Specifications

• Base Silicon: CYW20721
• Bluetooth Classic: Yes
• Bluetooth LE: Yes
• ADC Max Resolution: 12bit ENoB (audio), 10bit ENoB (DC)
• CPU Core: Arm Cortex-M4 at 96MHz
• Flash Memory: 1024 kByte
• SRAM: 512 kByte
• ROM: 2MB
• GPIOs: 17
• I2C: 1
• SPI: 2
• UART: 2
• PWM: 6
• PDM: 1
• Antenna Type: PCB trace antenna
• Operating Temperature: -30 to 85 degrees Celsius
• Voltage Range: 1.76V to 3.63V
• Size: 12 x 16.3 x 1.70 mm
• Package Name: MODULE-30 (002-23992)
• Packing Type: TAPE & REEL
• Halogen Free: Yes
• RoHS Compliant: Yes
