Cdi Torque TCQXX22A Torque Wrench Head 11/16 in Sae

Product Description

The CDI TORQUE TCQXX22A is an interchangeable torque wrench head designed for use with compatible CDI torque drive handles. It features an 11/16 inch, 12-point box end with a 15-degree offset profile, giving technicians better clearance in tight or angled fastener positions. The shank measures 0.735 inches and uses an X-type shank interface for secure mounting to the drive handle. Maximum rated torque is 200 foot-pounds. Measured in SAE units, this head suits mechanical, industrial, and automotive service work where controlled, repeatable torque application on hex fasteners is required.

This torque wrench head is intended for professional use in automotive repair, fleet maintenance, industrial assembly, and equipment service environments. The 15-degree offset box end allows access to fasteners in recessed or obstructed locations where a straight head would not fit. It is used by mechanics and service technicians working with SAE-standard fasteners requiring precise torque control up to 200 foot-pounds.

Key Features

• 11/16 inch 12-point box end for reliable engagement on SAE hex fasteners
• 15-degree offset head profile improves access in confined or angled workspaces
• X-type shank interface with 0.735 inch shank for secure drive handle connection
• Maximum torque rating of 200 foot-pounds
• SAE measurement type for standard inch-unit torque applications
• Compact and lightweight at 0.3 pounds for reduced hand fatigue during extended use

Compatibility

Designed as an interchangeable replacement or supplemental head for compatible CDI torque drive handles that accept the X-type shank interface.

Installation Notes

Installation and use should be performed by qualified mechanics or service technicians familiar with torque wrench systems. Ensure the shank is fully seated and locked into the drive handle before applying torque. Do not exceed the rated maximum torque of 200 foot-pounds. Inspect the shank interface for wear or debris before each use to maintain accurate torque transfer.

Technical Specifications

• Head Size: 11/16 inches
• Head Type: 15-Degree Offset Box End
• Point Type: 12 Point
• Maximum Torque: 200 ft-lb
• Shank Size: 0.735 inches
• Shank Type: X
• Measurement Type: SAE
• Length: 5.47 inches
• Width: 1.02 inches
• Height: 0.75 inches
• Weight: 0.3 pounds

Standard Information

• Brand: CDI TORQUE
• Manufacturer Part Number: TCQXX22A
