CARRIER ZP103KCE-TF5-950 Scroll Compressor AC/HP 105000 BTU

Product Description

The CARRIER ZP103KCE-TF5-950 is a scroll compressor designed for air conditioning and heat pump applications. With a cooling capacity of one hundred five thousand BTU, this compressor operates at voltages of two hundred twenty or two hundred thirty VAC and supports fifty or sixty Hz. Its hermetic design incorporates R-410A refrigerant and Polyolester oil, ensuring efficient performance.

• Features a seven eighths inch OD stub discharge connection.
• Incorporates a one and three eighths inch OD stub suction line fitting.
• Manufactured in the USA with UL recognition for safety.

Product Highlights

The CARRIER ZP103KCE-TF5-950 is engineered to efficiently manage liquid refrigerant slugs and debris. It has fewer moving parts, which enhances reliability and decreases maintenance needs. The design also reduces vibration, leading to lower operational noise and extended component lifespan.

Product Information

Standard Information

• Brand: CARRIER
• Application: AC/HP

Technical Specifications

• Weight: 134 lbs
• Dimensions: 10.38 × 11.23 × 21 inches
• Amps: 28.6-29
• BTU Output: 105000
• Compressor Type: Scroll
• Refrigerant: R-410A
• Sound Level: 77 dBA
• Voltage: 200/220, 200/230 VAC
