CARRIER P502-8304S Filter Drier - 1/2 in ODF

Product Description

The CARRIER P502-8304S filter drier is suitable for liquid lines using CFC, HCFC, and HFC refrigerants. This unit is built with a molecular sieve and activated alumina core that effectively filters particles down to twenty microns. It operates under a maximum working pressure of six hundred eighty PSI. The shell is made of painted steel, and it features copper connections. The nominal connection size is one-half inch ODF solder. This filter drier is UL listed and recognized for additional reliability. Measurements include nine point one inches in length and three point fourteen inches in both height and width.

• Protects against moisture, acids, and particulate contamination.
• Maintains system performance.
• Designed for liquid line applications.

Product Highlights

Product Information

Standard Information

• Brand: CARRIER
• MPN: P502-8304S

Technical Specifications

• Application: Liquid line
• Effective Volume of Desiccant: thirty cubic inches
• Core Material: Molecular sieve, activated alumina
• Connections Material: Copper
• Filtration: twenty microns
• Max Working Pressure: six hundred eighty PSI
• Refrigerant Compatibility: CFC, HCFC, HFC
• Weight: three point zero one pounds
• Dimensions: nine point one inches (Length) x three point fourteen inches (Height) x three point fourteen inches (Width)
