Carrier P502-8164S Filter Drier 1/2 inches ODF (16 cu)

Product Description

The Carrier P502-8164S is a 1/2" ODF filter drier designed for refrigeration and air conditioning liquid lines. The unit provides moisture and contaminant removal with a 16 cubic inch desiccant capacity and uni-directional flow. It features 1/2" ODF inlet/outlet, a maximum working pressure of 650 psig (4690 kPa), and compact dimensions suitable for inline installation in HVAC and refrigeration systems.

• 1/2" ODF solder inlet/outlet with uni-directional flow
• 16 cubic inch desiccant capacity; max working pressure 650 psig (4690 kPa)
• Designed for refrigeration and air conditioning liquid line moisture and contaminant removal

Product Highlights

Liquid line filter drier, 1/2" ODF connection, 16 cu in capacity, 650 psig max pressure

Product Information

Standard Information

• Brand: CARRIER
• Manufacturer Part Number: P502-8164S

Technical Specifications

• Brand: Carrier
• MPN: P502-8164S
• Manufacturer: Totaline
• Product Type: Liquid line filter drier
• Connection Type: 1/2" ODF (solder)
• Inlet/Outlet: 1/2" ODF solder
• Capacity: 16 cubic inches
• Flow Direction: Uni-directional
• Max Working Pressure: 650 psig (4690 kPa)
• Compatible Refrigerants: R-11, R-12, R-22, R-113, R-114, R-115, R-123, R-124, R-125, R-134a, R-401A, R-401B, R-402A, R-402B, R-404A, R-407A, R-407B, R-407C, R-410A, R-500, R-502, R-507
• Application: Refrigeration and air conditioning liquid lines
• Condition: New
• Dimensions: 7.00 x 1.70 x 1.70 inches
