CARRIER 5F60-623 Coupling

Product Description

The CARRIER 5F60-623 is a coupling designed to connect the ends of two shafts for rotary motion transfer. It allows for slight linear and angular misalignments between the shafts. The design includes keyways for added security, and features threaded holes for set screws, ensuring a stable attachment.

• Connects two shafts for rotary motion transfer.
• Accommodates slight linear and angular shaft misalignments.
• Features keyways and threaded holes for secure attachment.

Product Highlights

This coupling is ideal for various applications requiring reliable rotary motion transfer.

Product Information

Standard Information

• Brand: Carrier
• MPN: 5F60-623

Technical Specifications

• Item: COUPLING
• Condition: New
• Design Type: GRID SPRING
• Overall Length: 6.938 inches nominal
• Outside Diameter: 5.438 inches nominal
• Bore Shape: Straight first end tapered second end
• Bore Diameter: 1.6250 inches minimum and 1.6255 inches maximum first end
• Bore Length: 2.0000 inches nominal first end
• Taper Minor Diameter: 1.4840 inches nominal second end
• Taper Largest Diameter: 1.4850 inches nominal second end
• Keying Facility Quantity: 1 both ends
• Keying Facility Type: Keyway both ends
• Keyway Width: 0.250 inches nominal both ends
• Keyway Depth: 0.1250 inches nominal both ends
• Securing Method: Threaded hole both ends
• Threaded Hole Quantity: 2 both ends
• Threaded Hole Location: One located on top of key, one located ninety degrees from keyway both ends
• Thread Size Designator: 3/8 in.-24 both ends
• Furnished Items and Quantity: Setscrews 2
• Features Provided: Keyway and floating shaft
