Carlyle 06DM8246AC1250 High Temp Compressor No Oil

Product Description

The Carlyle 06DM8246AC1250 is a high-temperature compressor designed to provide reliable performance without the use of oil. This compressor features a high-flow, automatically reversible oil pump for positive displacement lubrication. The crankcase venting system helps equalize pressure during startup, ensuring effective oil return. An oversized sump captures extra oil to maintain safe lubrication levels during operation.

• High-capacity performance with contoured pistons
• Efficient refrigerant flow due to advanced valve design
• Integrated electronic oil-pressure switch for enhanced monitoring

Product Highlights

This compressor is suitable for a range of applications, providing effective cooling in high-temperature environments.

Product Information

Standard Information

• Brand: Carlyle
• Part Number: 06DM8246AC1250

Technical Specifications

• Weight: 273 lbs
• CFM: 24
• Compressor Housing: Semi-Hermetic
• Compressor Type: Screw
• Cycle/Hertz: 60 Hz
• Evaporating Temperature: 32°F to 53°F (0°C to 11.67°C)
• Motor HP: 7 1/2 HP
• Overall Length: 24 inches
• Voltage: 208-230 VAC
• Phase: Three
• Protection: Electromechanical Overcurrent Protection
• UL Listed: Yes
• Discharge Connection Type: Sweat or Braze
• Return Gas Temperature: 65°F (18.33°C)
• Refrigerant: Various
• Country of Origin: MEX
