Carlin Combustion Technology 27730S 23044S 816CRD Motor 3/4HP

Product Description

The Carlin Combustion Technology 27730S is an oil burner motor with a power rating of 3/4 HP. It operates at 115/208 to 230 Volt AC 1-Phase and a frequency of 60 Hertz, with a speed of 3450 RPM. This motor is designed for use on the 801CRD oil burner.

• Power Rating 3/4 HP
• Voltage Rating 115/208 to 230 Volt AC 1-Phase
• Speed Rating 3450 RPM

Product Highlights

Designed for use with the 801CRD oil burner, this motor provides reliable performance for your heating needs.

Product Information

Standard Information

• Brand: CARLIN COMBUSTION TECHNOLOGY
• Manufacturer Part Number: 27730S

Technical Specifications

• CATALOG NUMBER: 27730S
• Category: HVAC/R & Fans
• Description: Oil Burner Motor; Power Rating 3/4 HP; Voltage Rating 115/208 to 230 Volt AC 1-Phase; Frequency Rating 60 Hertz; Speed Rating 3450 RPM; Application Oil Burner; Used On 801CRD Oil Burner
• Frequency Rating: 60 Hertz
• Manufacturer Name: Carlin Combustion Technology
• Manufacturer Part Number: 27730S
• Power Rating: 3/4 HP
• Speed Rating: 3450 RPM
• Application: Oil Burner
• Used On: 801CRD Oil Burner
• Applicable Standard: UL (Canada and US)
• Used On Item: Commercial Oil Fired Burner
• Used On Model/Brand: 801CRD
• Starting Current: 9.8 Amp
• Rotation Type: Clockwise
• MPN: 27730S
• Manufacturer: Carlin
• Diameter: 5.69"
• Series: CARLIN BURNER MOTORS
• Brand: Carlin Combustion Technology, Inc
• HP: 3/4
• RPM: 3450
• Voltage: 115/208/230V
• Phase: Single Phase
• Frame: 48N
