Cadweld TAC3D2Q ERC TAC3D2Q HOR TEE CABLE MOLD

Product Description

The Cadweld TAC3D2Q is a welding mold designed for horizontal tee cable to cable connections. This product is built to accommodate a main cable size of three hundred fifty KCMIL and a concentric tap cable size of four aught AWG. It features weld metal type fifteen zero/fifteen PLUS F20 and comes equipped with a handle clamp type L160. The outer diameter of the conductor is zero point six eight one inches by zero point five two eight inches.

• Horizontal tee design for cable welding
• Compatible with 350 KCMIL and 4/0 AWG cables
• Includes L160 handle clamp for secure operation

Product Highlights

The TAC3D2Q mold is essential for efficient cable connections in various electrical applications.

Product Information

Standard Information

• Manufacturer: Cadweld
• UPC: 78285655404

Technical Specifications

• Main Cable Size: 350 KCMIL
• Concentric Tap Cable Size: 4/0 AWG
• Weld Metal Type: 150/150PLUSF20
• Handle Clamp Type: L160
• Conductor Outer Diameter: 0.681 inches x 0.528 inches
• Country Of Origin: USA
• Package Weight: 1.3200 lbs
