CADWELD TAC2V2GW Cable to Cable Mold

Product Description

The CADWELD TAC2V2GW is a mold that helps create cable to cable connections. This mold is made for a 250 kcmil concentric conductor and a 2/0 concentric conductor. It is part of the TA mold family and features a horizontal split, making it suitable for efficient use. Wear plates are included, and welding material and handle clamps need to be purchased separately.

• Forms a permanent and reliable connection
• Creates a molecular bond for durability
• Connections can be easily inspected

Product Highlights

This mold simplifies the process of forming connections between cables while ensuring low resistance.

Product Information

Standard Information

• Brand: CADWELD
• MPN: TAC2V2GW

Technical Specifications

• Mold Family: TA
• Conductor 1: 250 kcmil Concentric
• Conductor 1 Outer Diameter, Nominal: 14.61 mm
• Conductor 2: 2/0 Concentric
• Conductor 2 Outer Diameter, Nominal: 10.62 mm
• Mold Split: Horizontal
• Wear Plates: Yes
• Number of Wear Plate Sets: 3
