CADWELD PTC2G1T Cable to Cable Mold

Product Description

The CADWELD PTC2G1T is a graphite mold designed for making cable to cable connections. This mold accommodates a two-aught concentric cable with a nominal outer diameter of ten point six millimeters and a number two solid cable with a nominal outer diameter of six point five millimeters. It facilitates a parallel splice between cables. Exothermic connections made with this mold meet the current capacity of the conductor.

• Forms a permanent, low resistance connection.
• Provides a molecular bond between cables.
• No external power source is needed for installation.

Product Highlights

The CADWELD PTC2G1T offers versatile and reliable cable splicing solutions. Ideal for both professional and DIY applications, this mold simplifies the installation process and enhances connection strength.

Product Information

Standard Information

• Brand: CADWELD
• MPN: PTC2G1T

Technical Specifications

• Mold Family: PT
• Conductor 1: 2/0 Concentric
• Conductor 1 Outer Diameter, Nominal: 10.62 mm
• Conductor 2: #2 Solid
• Conductor 2 Outer Diameter, Nominal: 6.53 mm
• Mold Split: Vertical
• Country of Manufacture: United States
• UPC: 782856548157
