Bussmann SC-1/2 SC Fuse 0.5 A

Product Description

The Eaton Bussmann Series SC-1/2 is a Class G, fast-acting, current limiting fuse. This 0.5 A fuse has a rejection style and an interrupting rating of 100 kA at 600 Vac and 10 kA at 170 Vdc. It is suitable for sensitive current protection devices that respond rapidly to changes in current.

• Fast-acting
• Current limiting
• Rejection style

Product Highlights

The Bussmann SC-1/2 fuse provides reliable and quick protection for current-sensitive equipment with its fast-acting and current limiting features.

Product Information

Standard Information

• Brand: BUSSMANN
• Manufacturer Part Number: SC-1/2
• Country of Origin: China

Technical Specifications

• Product Name: Eaton Bussmann series SC fuse
• Catalog Number: SC-1/2
• UPC: 051712250009
• Product Length/Depth: 1.31 in
• Product Height: 0.41 in
• Product Width: 0.41 in
• Product Weight: 0.1 lb
• Compliances: CE Marked RoHS Compliant
• Product Type: Fuse
• Amperage Rating: 0.5 A
• Interrupt rating: 100 kAIC at 600 Vac 10 kAIC at 170 Vdc
• Voltage rating: 600 Vac, 170 Vdc
• Packaging type: Standard
• Class: Class G
• Connection: Ferrule end x ferrule end
• Fuse indicator: Non-indicating
• Special features: Rejection style
• Amps: 1/2
• Voltage: 600
• Actuation Type: Fast Acting
• Voltage AC: 600 V AC
• Voltage DC: 170 V DC
• Interrupting Rating: 100,000 AIC RMS @ 600VAC
• Interrupting Rating DC: 10,000A @170VDC
• Brand: BUSSMANN
• Country of Origin: China
• Mfr. #: SC-1/2
• Description: Industrial & Electrical Fuses 600VAC/170VDC .5A Time Delay
• Current Rating: 500 mA
• Dimensions: 0.41 in H X 0.41 in W X 1.31 in L
• Indicator: Non-indicating
• Manufacturer Part Number: SC-1/2
• Shape: RECTANGULAR
• Type: Fuse
• UPC Code: 51712250009
• Series: SC
• Part Number: SC 021
• Mfg Cat No: SC-1/2
• VAC: 600
• Body Material: Melamine
• Compatible Fuse Block Series: BG30
• Element: Single
• Fuse Block Style: Rejection
• Fuse Body Style: Cylindrical
• Fuse Class or Type: G
• Fuse Diameter: 13/32 in
• Fuse Diameter x Length: 13/32 in x 1-5/16 in
• Fuse Length: 1-5/16 in
• Interrupt Rating - AC: 100 kA
• Interrupt Rating - DC: 10 kA
• Speed: Fast-Acting
• Standards: CE; CSA Guide 1422-01; UL 248-5 Guide JDDZ
• Visual Indication: Non-Indicating
