Bussmann GMT-1/4A Eaton Bussmann series GMT telecommunication fuse 0.25 A

Product Description

The Eaton BUSSMANN GMT-1/4A series GMT telecommunication fuse features a color code violet, is rated for 125 Vac, 60 Vdc, and 0.25 A. It is non-indicating and fast-acting, with a tin-plated beryllium copper terminal. This fuse is designed for telecommunications, computer, or control circuits.

• Color code violet
• Non Indicating
• Fast-acting
• Tin-plated beryllium copper terminal

Product Highlights

The Bussmann GMT fuse is ideal for telecommunications, computer and control circuits. It is fast acting and non-indicating.

Product Information

Standard Information

• Brand: BUSSMANN
• Manufacturer Part Number: GMT-1/4A
• Country of Origin: MX - Mexico

Technical Specifications

• Product Name: Eaton Bussmann series GMT telecommunication fuse
• Catalog Number: GMT-1/4A
• UPC: 051712576697
• EAN: 5027590093118
• Product Length/Depth: 0.78 in
• Product Height: 0.62 in
• Product Width: 0.11 in
• Compliances: CE Marked RoHS Compliant
• Product Type: Telecommunication fuse
• Amperage Rating: 0.25 A
• Voltage rating: 125 Vac, 60 Vdc
• Packaging type: Standard
• Fuse indicator: Non-indicating
• Special features: Color code violet
• Amperage: 1/4 Amps
• Voltage: 125 Volts AC/60 Volts DC
• Fuse Type: Telecom Protection Fuse
• Speed: Fast Acting
• Body Material: Plastic
• Rejection: Non-Rejection
• Interrupting Rating: 300A @ 125vac, 450A @60vdc
• Physical Size: 13/16" Length
• Additional Information: Tin-Plated Beryllium Copper Terminal
• Suitable For Use With: HLT, HLS and PCT Fuse Holders and Telpower 15800 Fused Disconnect Switch
• Length: 0.78 in.
• Height: 0.62 in.
• Width: 0.11 in.
• Ampere: .25 A
• Interrupt rating: 300A
• Shape: Flat Body Blade Fuses
• Approvals: CE, UL
• Dimensions: .688" Dia x .780" L (17.48x19.81mm)
• Other names: BK/GMT-1/4, BK-GMT-1/4A, GMT-1/4, GMT-1/4A, BK/GMT1/4, BK-GMT1/4, BK/GMT1/4A, GMT1/4, GMT1/4A
• ECCN: EAR99
• Application: Telecommunications DC power circuit protection
• Material: Tin-plated beryllium copper terminal
• Rated Voltage: 125V ac/60V dc
• Fuse Amps: 0.25 A
• UNSPSC Code: 39120000
• Brand: Bussmann by Eaton
• Current Rating: 0.25 A
• Indicator: Non-indicating
• Manufacturer Part Number: BK/GMT-1/4A
• Type: Telecommunication fuse
• Unit of Measure: EA
