Bussmann FNQ-5-6/10 Fuse 5.6A

Product Description

The Eaton Bussmann Series FNQ-5-6/10 is a Class CC, time-delay, dual-element, current limiting fuse. This 5.6A rejection style fuse has an interrupting rating of 200kA at 600Vac and is suitable for line protection, small control transformers, industrial control, and branch circuits.

• Time-delay
• Dual-element
• Current limiting
• Rejection style

Product Highlights

The Bussmann FNQ-5-6/10 fuse offers reliable circuit protection with its time-delay, dual-element design and high interrupting rating.

Product Information

Standard Information

• Brand: BUSSMANN
• Manufacturer Part Number: FNQ-5-6/10
• Country of Origin: China

Technical Specifications

• Product Type: Fuse
• Catalog Number: FNQ-R-5-6/10
• UPC: 051712582438
• Product Length/Depth: 1.5 in
• Product Height: 0.41 in
• Product Width: 0.41 in
• Amperage Rating: 5.60A
• Class: Class CC
• Interrupt rating: 200 kAIC
• Fuse indicator: Non-indicating
• Connection: Ferrule end x ferrule end
• Response time: 12 sec at 200%
• Material: Melamine tube
• Packaging type: Standard
• Voltage rating: 600 V
• Type: Current-limiting high inrush time-delay fuse
• Special features: Rejection style
• Application: Line protection, small control transformers, industrial control, branch circuits
• Amps: 5 6/10
• Voltage AC: 600
• Fuse Size: Midget
• Speed: Time Delay
• Physical Size: 13/32" x 1 1/2"
• Use: For Circuits with Inrush Currents
• AC Voltage Rating: 600
• Interrupting Rating: 10,000 AIC @ 600VAC
• UL Listed: STD 248-14, Guide JDYX, File E19180
• CSA Certified: Class 1422-01; File 53787
• Brand: Eaton Bussmann
• Series: FNQ-R
• Mpn: FNQ-R-5-6-10
• Gtin: 51712582438
• Condition: New
• Category: Business & Industrial>Electrical Equipment & Supplies>Fuses>Fuses & Links
