Bussmann ECSR200 UL Class RK-5 Time Delay Fuse 200 A

Product Description

The Bussmann ECSR200 is a UL Class RK-5 time delay fuse with a current rating of two hundred amps. This fuse provides superior overload protection and cycling capabilities. Its design features a blade end connection and is non-indicating. The ECSR200 can handle up to two hundred kiloamperes interrupting current and is rated for six hundred volts.

• Time-delay current limiting capabilities
• Rated for a maximum voltage of six hundred volts
• Ideal for AC power distribution systems, motors, and inductive loads

Product Highlights

This fuse supports applications in AC power distribution, feeders, branch circuits, and lighting systems.

Product Information

Standard Information

• Brand: Bussmann
• Manufacturer: Edison Fuse

Technical Specifications

• MPN: ECSR200
• Voltage: 600 Volt
• Amperage: 200 Amp
• Interrupt Rating: 200 kAIC
• Response Time: 10 Seconds at 500%
• End Type: Blade
• Diameter: 1.61 Inch
• Length: 9.63 Inch
• Weight: 1.5 lb
• Applications: AC Power Distribution System Mains, Feeders, Branch Circuits, Motors and Motor Branch Circuits, Transformers, Lighting, Heating
