Bussmann ANN-350 ANN Series Circuit Limiter 350A

Product Description

The BUSSMANN ANN-350 is an Eaton Bussmann series ANN circuit limiter. This 350A limiter has a 2.5 kAIC interrupt rating at 125 Vac and 2.7 kAIC at 80 Vdc. It features blade end x blade end connection and stud mounting. It is a non-indicating limiter with a small footprint.

• Small footprint
• Very Fast Acting
• Isolates faults in battery operated systems

Product Highlights

The BUSSMANN ANN-350 circuit limiter is ideal for aviation, forklifts, and marine applications.

Product Information

Standard Information

• Brand: BUSSMANN
• Manufacturer Part Number: ANN-350
• Country of Origin: MX - Mexico

Technical Specifications

• Product Name: Eaton Bussmann series ANN circuit limiter
• Catalog Number: ANN-350
• UPC: 051712706407
• EAN: 5027590400954
• Product Length/Depth: 3.38 in
• Product Height: 1.62 in
• Product Width: 0.95 in
• Product Weight: 0.27 lb
• Product Type: Circuit limiter
• Amperage Rating: 350 A
• Interrupt rating: 2.5 kAIC at 125 Vac 2.7 kAIC at 80 Vdc
• Voltage rating: 125 Vac, 80 Vdc
• Connection: Blade end x blade end
• Fuse indicator: Non-indicating
• Mounting method: Stud
• Special features: Small footprint
• Amps: 350A
• Volts AC: 125
• Application: Aviation, fork lifts, marine
• Speed: Very Fast Acting
• AC Voltage Rating: 125V AC
• DC Voltage Rating: 80V DC
• Interrupting Rating: 2,700 AIC @ 80VDC
• Brand / Manufacturer: BUSSMANN FUSES
• Voltage: 125
• Series: ANN
• SKU: ANN-350
• ECCN: EAR99
• UNSPSC: 39121626
• Connection Type: Blade end x blade end
• Mounting Type: Stud
• Fuse Interrupt Rating: 2.5 kAIC at 125V ac
• Fuse Type: Circuit Limiter
• Rated Voltage: 125V ac/80V dc
• Shape: Rectangular
• Fuse Amps: 350A
• Length: 3.38 in.
• Height: 1.62 in.
• Width: 0.95 in.
• MFR #: ANN-350
• Item: Limiter Fuse
• Body Style: Bolt-On
• Visual Indication: Indicating
• Body Material: Glass/Melamine
• Equivalent Brand and Series: Bussmann ANN, Littelfuse CNN, Mersen CNN
• Equivalent Series: ANN, CNN
• Fits Fuse Block Style: Non-Rejection
• Indicating / Nonindicating: Indicating
• Fuse Speed: Very Fast Acting
• Fuse Voltage Rating: 125VAC/80VDC
• Element: Single
• Standards: CE, CSA Certification Class 1422-30, UL Guide JFHR2
• Compatible Fuse Block Series: 4164
• Current: 350 A
• Interrupt Rating - AC: 2.5 kA
• Interrupt Rating - DC: 2.7 kA
• Overall Length: 3 3/16 in
• Physical Size: 0.88" x 3.19"
• Diameter: 7/8 in
• Overall Diameter: 7/8 in
