Bullard 24663 Turbo Grinding Wheel 6x1/4x7/8 Metal

Product Description

The BULLARD 24663 is a Type 27 depressed center turbo grinding wheel built for metal grinding and light cut-off work in demanding trade applications. Rated at 10200 RPM, this 6 x 1/4 x 7/8 inch wheel is engineered for combination cutting and light grinding in a single pass, so technicians and ironworkers do not need to swap wheels or tools mid-job. The turbo design delivers a smooth grind with consistent material removal and solid operator control. Weighing 0.6 pounds, it is sized for use on standard 6-inch angle grinders in fabrication, pipeline, and structural metalwork settings.

This wheel is designed for pipeline and structural metal applications where both cutting and light grinding are required in the same workflow. The Type 27 depressed center profile allows flush and angled grinding access to welds, pipe joints, and plate edges. It is suited for use by ironworkers, pipefitters, welders, and general tradespeople working with ferrous metals. The 6-inch diameter and 1/4-inch thickness make it appropriate for fast material removal and surface preparation tasks on metal substrates.

Key Features

• Type 27 depressed center design for flush and angled grinding access
• Turbo profile enables combination cutting and light grinding in one wheel
• Rated at 10200 RPM for use on standard 6-inch angle grinders
• 1/4-inch thickness supports fast metal grinding with smooth finish
• 7/8-inch arbor hole fits common angle grinder spindle sizes
• Lightweight at 0.6 pounds for reduced operator fatigue during extended use

Compatibility

Designed as an OEM-style replacement or direct-use grinding wheel for standard 6-inch angle grinders with a 7/8-inch arbor and a maximum speed rating of 10200 RPM or higher.

Installation Notes

Grinding wheel installation and use should be performed by qualified trade professionals following ANSI B7.1 safety standards for abrasive wheel tools. Before mounting, confirm the grinder's rated RPM meets or exceeds the wheel's 10200 RPM rating and that the arbor size matches. Always power down and unplug the grinder before changing wheels, and inspect the wheel for cracks or damage before each use. Wear appropriate PPE including face shield, gloves, and hearing protection during operation.

Technical Specifications

• Wheel Type: Type 27 Depressed Center
• Wheel Diameter: 6 inches
• Thickness: 1/4 inches
• Arbor Size: 7/8 inches
• Maximum Speed: 10200 RPM
• Weight: 0.6 pounds
• Application: Metal Grinding and Light Cut-Off

Standard Information

• Brand: BULLARD
• Manufacturer Part Number: 24663
