Bullard 20738 Type 27 Turbo Cutoff Grinding Wheel 7in

Product Description

The BULLARD 20738 is a Type 27 depressed-center turbo wheel engineered for combination cutting and light grinding in a single application. Measuring 7 inches in diameter with a 1/8-inch thickness and a 5/8-11 arbor, it runs at a maximum of 8500 RPM and carries a Grit 30 abrasive specification. The depressed-center profile keeps the work surface accessible during both cut-off and grinding passes, reducing the need to swap wheels or tools mid-task. Licensed tradespeople working pipeline, structural steel, and fabrication applications will find this wheel suited to demanding material removal and finishing in one setup.

This wheel is designed for pipeline and structural steel work where a single wheel must handle both cutting and light grinding without tool changes. The Grit 30 abrasive provides aggressive stock removal while the turbo segment geometry promotes smooth, controlled passes. It is well suited to field welding prep, pipe fitting, and light weld cleanup in residential, commercial, and industrial fabrication environments. Each wheel is sold individually with a minimum order quantity of 10 units.

Key Features

• Type 27 depressed-center profile for flush cutting and grinding access
• Turbo segment geometry delivers smooth grinding control in pipeline applications
• Dual-purpose design handles both cut-off and light grinding in one wheel
• 5/8-11 arbor fits standard angle grinders used in trade and fabrication work
• 8500 RPM max speed rating supports common 7-inch grinder speeds
• Grit 30 abrasive for aggressive cutting and light material removal

Compatibility

Designed as an OEM-style replacement and standard fitment for 7-inch angle grinders with a 5/8-11 threaded spindle.

Installation Notes

Installation and wheel changes must be performed by a qualified operator following ANSI B7.1 safe-use requirements for abrasive wheels. Always power down and disconnect the grinder from its power source before mounting or removing the wheel. Inspect the wheel for cracks or damage before each use and never exceed the rated maximum RPM. Wear appropriate PPE including a face shield and gloves during operation.

Technical Specifications

• Wheel Type: Type 27 Depressed Center
• Diameter: 7 inches
• Thickness: 1/8 inch
• Arbor Size: 5/8-11
• Maximum RPM: 8500 RPM
• Grit: 30
• Weight: 0.75 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 10

Standard Information

• Brand: BULLARD
• Manufacturer Part Number: 20738
