Bryant CSB115BW Wall Switch, 1-Pole, Locking No, Toggle

Product Description

The BRYANT CSB115BW is a wall switch featuring a 1-pole configuration with a locking mechanism and toggle operation. This commercial-grade, single-pole switch is rated for 15A at 120/277V AC and is designed for back and side wiring. It is suitable for general-purpose AC applications.

• Single pole switch
• 15A 120/277V AC
• Back and side wired

Product Highlights

Commercial grade toggle switch for general purpose AC applications.

Product Information

Standard Information

• Brand: BRYANT
• Manufacturer Part Number: CSB115BW
• Country of Origin: CN

Technical Specifications

• Catalog Number: CSB115BW
• Color: White
• Series: General Purpose
• Style: Single Pole
• Type: Toggle
• UPC: 781786736306
• Amperage Rating: 15 A
• Voltage Rating: 120/277 VAC
• Carton Quantity: 10
• Country of Origin: CN
• MPN: R0173
• Features: Wall Switch, Color White, Current Rating 15 A, Switch Function Maintained, Switch Type Single Pole, Voltage Rating 120/277V AC, Wiring Method Back, Side, Horsepower Rating 2 hp, Locking Style Not Applicable, Number of Switches 1, Standards CSA Certified, Switch Style Toggle, Wire Connection Type Screw Terminals, Market Commercial, Overall Height 1.66 in
• Brand: ZORO SELECT
• Model: CSB115BW
• Electrical switch type: Toggle Switch
• Amps: 15 Amps
• Volts: 120 V
• Number of poles: 1
• Light dimmer & switch style: Toggle
• Manufacturer Part Number: CSB115BW
• Manufacturer: Bryant Electric
• Family Series: Bryant Electric Switches
• Grade: Commercial
• Switch Configuration: Single Pole
• Voltage: 120 VAC, 277 VAC
• Current Rating: 15 A
• Operator Color: White
• Illuminated: No
• Locking: No
• Wiring: Back and Side Wired
• Approvals: CSA, UL
• Comments: Self-Grounding
