Bryant 9326 Receptacle Single 20A 250V 10-20R

Product Description

The BRYANT 9326 is a flush mount single receptacle designed for commercial and industrial use. This heavy-duty, thermoset receptacle is side wired and supports 20A and 250V. It is suitable for standard installations where electrical performance and durability are required.

• Flush Mount Single
• Commercial/Industrial Grade
• Thermoset
• Side Wired
• 20A 250V

Product Highlights

This receptacle is ideal for industrial applications requiring a robust and reliable power connection.

Product Information

Standard Information

• Brand: BRYANT
• Manufacturer Part Number: 9326
• Country of Origin: US

Technical Specifications

• Application: Industrial Grade
• Catalog Number: 9326
• Color: Black
• Environmental Conditions: Indoor Dry Unless Protected By Additional Means
• EU RoHS Indicator: No
• Item Type: Single
• Material - Mounting Hardware: Screw Mounting
• OEM Brand Name: Hubbell Bryant
• Series: Heavy Duty
• Style: Finder Groove Face
• Type: Receptacle
• UPC: 781786632462
• Amperage Rating: 20 A
• Connectivity: Side Wired Only
• Current Rating: 20 A
• Phase: Single Phase
• Voltage Rating: 125/250V AC
• Voltage Rating Description: 250 V
• Number Of Poles: 3-Pole
• Number Of Wires: 3-Wire
• Wire Size: #14 AWG to #12 AWG
• Nema Rating: 10-20R
• Mounting Style: Flange, Flush
• Material: Nylon, Brass
• Outlet Style: Single
• Voltage: 250VAC
• Model: 9326
• Number of Outlets: 1
• Outlet Configuration: Single
• Features: Heavy Duty
• MFR #: 9326
• UPC #: 781786632462
• Country of Origin: United States
• Maximum Wire Size: 12 AWG
• Minimum Wire Size: 14 AWG
• Item: Straight Blade Receptacle
• Receptacle Type: Single
• NEMA Receptacle Configuration: 10-20R
• Number of Poles: 3
• Number of Wires: 3
• Wire Connection Type: Screw Terminals
• Wiring Method: Side
• Grounding: Non-Grounded
• Housing Material: Thermoplastic
• Mount Type: Flush
• Standards: CSA Certified, UL Listed
• Flange Type: Non-Flanged
• Outlet Type: Single
• Mounting Type: Flush
• NEMA Receptacle Configuration - Plugs and Receptacles: 10-20R
• Tamper Resistant: No
• Sub-Category: Single Receptacles
• Number of Gangs: 1
• Surge Suppression: No
• Wiring Method - Plugs and Receptacles: Side
• Weather Resistant - Plugs and Receptacles: No
• Application Environment: Industrial
• Weather Resistant: No
• Corrosion Resistant: No
• Outlet Type - Plugs and Receptacles: Single
• Mounting Type - Plugs and Receptacles: Flush
• Power Indicator: No
• Connection Orientation: Straight
• Market: Industrial
• AFCI: No
• GFCI: No
• Polarized: Yes
• Includes: Mounting Hardware
• Grade: General Use
• Surge Protection: No
• Cover Type: No Cover
• IP Rating: IP20
• Mounting Location: Outlet Box
• Number of Wall Plates Included: 0
• UNSPSC: 39121406
