Bryant 71120ER Flanged Outlet N L11-20R

Product Description

The BRYANT 71120ER is a flanged outlet with NEMA configuration L11-20R. This industrial flanged receptacle is rated for 20A, 3-Phase Delta 250V AC, and features a 3-pole, 3-wire non-grounding design with screw terminals. It is suitable for indoor dry environments when protected by additional means.

• Impact resistant thermoplastic construction
• Backwired terminations for ease of installation
• #10-32 Multiple drive terminal screws

Product Highlights

Industrial flanged receptacle, 20A, 3-Phase Delta 250V AC, 3-Pole 3-Wire Non-Grounding, L11-20R, Screw Terminal.

Product Information

Standard Information

• Brand: BRYANT
• Manufacturer Part Number: 71120ER
• Country of Origin: US

Technical Specifications

• Manufacturer Part Number: 71120ER
• Manufacturer: Bryant Electric
• Family Series: Bryant Electric Plugs & Receptacles
• Current Rating: 20 A
• Number of Poles: 3
• Number of Wires: 3
• Voltage: 250 VAC
• Phase: 3
• Body Type: Straight
• Connection Type: Flanged Outlet
• NEMA Configuration: L11-20R
• Watertight: No
• Isolated Ground: No
• Color: White
• Approvals: CSA, UL
• Application: Extra Heavy Duty Industrial Specification Grade
• EU RoHS Indicator: Yes
• Item Type: 20A Flanged Receptacle
• Material: Composite
• Material - Mounting Hardware: Screw Mounting
• OEM Brand Name: Hubbell Bryant
• Style: Equipment Base
• Type: Flanged Receptacle
• UPC: 781786693302
• Amperage Rating: 20 A
• Connectivity: Terminal Screws
• Current Amperage Description: 20 Amp
• Voltage Rating: 3 Phase 250 VAC
• Voltage Rating Description: 3 Phase 250V AC
• Number Of Poles: 3-Pole
• Number Of Wires: 3-Wire
• Wire Size: #14 AWG to #8 AWG
• Standards - RoHS Compliance Status: CM
• Environmental Conditions: Indoor Dry Unless Protected By Additional Means
• Wattage: 5,000 W
• Brand ID: BRYANT
• Description - Long: Locking Devices, Industrial, Flanged Receptacle, 20A 3-Phase Delta 250V AC, 3-Pole 3-Wire Non-Grounding, L11-20R, Screw Terminal, White.
• Description - Short: Locking Devices, Industrial, Flanged Receptacle, 20A 3-Phase Delta 250V AC, 3-Pole 3-Wire Non-Grounding, L11-20R, Screw Terminal, White
• FV_Current/Amperage Rating Description: 20 Amp
• FV_Voltage Rating Description: 3 Phase 250V AC
• Product Name: 71120ER
• Part #: 71120ER
• Category: Plug/Receptacle
