Browning AK99H 9.75OD CI Sheave, Split Taper

Product Description

This is the Browning AK99H sheave, with a diameter of nine point seventy-five inches. This sheave features a split taper design for easy installation and removal, making it suitable for various industrial applications. Crafted from cast iron, it ensures durability and strength. The construction is designed to handle high loads, making it reliable for power transmission tasks.

• Split taper design for ease of installation
• Manufactured from strong cast iron
• Suitable for high-load applications

Product Highlights

This sheave is ideal for use in industrial machinery and conveyor systems, delivering dependable power transmission.

Product Information

Standard Information

• Brand: Browning
• Item Number: AK99H

Technical Specifications

• Weight: 4.80 lbs
• Material: Cast Iron
• Bore Type: Split Taper Bushed
• Face Width: 0.7500 inches
• Overall Width: 1.5000 inches
• Pitch Diameter: 9.1600 inches (3L), 9.7000 inches (A)
• Outside Diameter: 9.7500 inches
• Number of Grooves: 1
• Bushing Series: H
• Length Through Bore: 1.2500 inches
