Browning 1298082 Offset Link Double Strand 40-2 Chain

Product Description

The BROWNING 1298082 is an offset link designed for use with double strand roller chain in industrial drive and conveyor applications. With a 1/2 inch pitch and ANSI 40-2 designation, this link provides a reliable method for joining or shortening a double strand chain run where a standard connecting link cannot be used. It meets ANSI standards for chain hardware and is a direct fit for 40-2 roller chain. Maintenance technicians and industrial mechanics install this type of link during chain replacement or repair on power transmission assemblies.

This offset link is suited for industrial machinery, conveyor systems, and mechanical power transmission equipment that runs 40-2 double strand roller chain. It is commonly installed during scheduled maintenance intervals when chain length must be adjusted or a damaged section needs to be replaced without pulling a full new chain. The compact size and low weight make it a practical item to keep in a service kit for quick field repairs.

Key Features

• ANSI 40-2 rated for double strand roller chain applications
• 1/2 inch pitch matches standard 40-series chain dimensions
• Offset link design allows joining where full links are not practical
• Meets ANSI standards for chain connecting hardware
• Lightweight at 0.05 pounds for easy handling and stocking

Compatibility

Designed for use with ANSI 40-2 double strand roller chain with a 1/2 inch pitch.

Installation Notes

Installation is performed by qualified maintenance mechanics or industrial technicians. Always de-energize and lock out the drive system before working on any chain assembly per applicable LOTO procedures. Use a proper chain breaker tool to seat the offset link correctly and avoid deforming the side plates. Do not use offset links as a permanent solution on high-speed or high-load drive applications unless the chain manufacturer specifications permit it.
