Browning 1295294 Clutch Torque Guard Sprocket 28 Tooth

Product Description

The BROWNING 1295294 is a steel clutch torque guard with sprocket designed for use in mechanical power transmission systems. With 28 teeth and a 1-inch pitch, this component transfers torque reliably between drive elements while providing overload protection through its torque-limiting design. It measures 9.48 inches in overall height and 6.35 inches in overall width, with a chain engagement width of 0.575 inches. Licensed HVAC techs, millwrights, and industrial mechanics working on belt-and-sprocket drive trains will find this part a direct-fit solution for systems equipped with the Torq Gard 400 clutch platform.

This torque guard sprocket is intended for use with the Torq Gard 400 system, a mechanical overload clutch platform common in industrial conveyor, agricultural, and general-purpose drive applications. It is suited for installations where drivetrain overload protection is required and where a sprocket must be integrated directly with the clutch body. The steel construction makes it appropriate for moderate to heavy-duty duty cycles in both indoor and sheltered outdoor environments.

Key Features

• 28-tooth sprocket integrated with torque guard clutch body for compact drivetrain overload protection
• 1-inch pitch compatible with standard roller chain sizes used in industrial drive systems
• Steel construction for durability in demanding mechanical environments
• Overall height of 9.48 inches and overall width of 6.35 inches for predictable dimensional fit
• Chain engagement width of 0.575 inches for precise chain alignment
• Designed for use with the Torq Gard 400 clutch platform

Compatibility

Designed for use with the Torq Gard 400 clutch system. Consult BROWNING documentation to confirm compatibility with specific shaft sizes, chain standards, and drive configurations before installation.

Installation Notes

Installation should be performed by a qualified mechanic or industrial technician familiar with mechanical power transmission components. Disengage and lock out all power to the drive system before beginning any installation or service work, following OSHA lockout/tagout procedures. Verify shaft diameter, keyway dimensions, and chain pitch match the sprocket specifications prior to mounting. Do not exceed the torque guard rating for the Torq Gard 400 system as specified in the manufacturer documentation.
