Bridgeport 253-USI Concretetight Insulated Throat Compression Connector 1-1/4 in

Product Description

Bridgeport Compression Connector with MPN 253-USI is designed for use with EMT conduit. This connector features an insulated throat and is made from steel with an electro-plated zinc finish. It is suitable for connecting EMT to boxes or enclosures.

• For use with EMT conduit
• Dimensions: 2.188 inches long
• Meets UL and NEMA standards

Product Highlights

This compression connector ensures a secure fit and reliable performance for electrical applications.

Product Information

Standard Information

• Manufacturer: Bridgeport Fittings
• Model: 253-USI

Technical Specifications

• Type: Concretetight Insulated Throat
• Material: Steel
• Finish: Electro-Plated Zinc
• Dimensions: 2.188 inches long
• Trade Size: 1-1/4 inches
• Application: For use to join EMT to box or enclosure
• Suitable For Use With: EMT Conduit
• Standards/Approvals: Federal Specification A-A-50553, NEMA FB-1 Rated, RoHS Compliant, UL 514B File No. E24001, UL Listed
