Honeywell P658E1001 Panel Mounted Pneumatic/Electric Switch 2-17 Psi Adjustable

Product Description

The Honeywell P658E1001 Panel Mounted Pneumatic/Electric Switch is designed to convert a pneumatic signal from a controller into an electrical switching action. This switch is panel mounted and has a 2-17 psi adjustable range.

• Panel mounted switch
• 2-17 psi adjustable range
• No factory set psi

Product Highlights

This switch from Honeywell is ideal for start and stop control of equipment such as fans and pumps. The absence of a case allows for flexible installation, making it suitable for various mechanical systems.

Product Information

Standard Information

• Brand: Honeywell
• MPN: P658E1001
• Category: Industrial & Scientific

Technical Specifications

• Switch Type: Pneumatic/Electric Switch
• Switching Action: Make COM-NO on pressure rise to setpoint plus differential, Make COM-NC on pressure fall to setpoint
• Air Connections: Barb fitting for 1/4 inch O.D. plastic tubing
• Electrical Connections: Screw terminals
• Frequency: 60 Hz
• Maximum Safe Operating Pressure: 30 psi
• Differential Pressure Range: 2 psi
• Motor Load: 3/4 hp at 125, 250 or 277 Vac
• Pilot Duty Ratings: 750 VA at 125, 250 or 277 Vac
• Resistive Load: 25A at 125, 250 or 480 Vac
• Setpoint Range (Field Adjustable): 2 to 17 psi
• Calibration: No Factory Calibration
• Mounting: Panel Mount
• Operating Humidity Range: 5 to 95% RH, 80 F max wet bulb
• Temperature Range: 40 F to 140 F
• Dimensions: 3 1/4 in. high x 2 7/8 in. wide x 1 3/4 in. deep
