Brasstech 517-10-24S Ceiling Mount Arm Flange 10 in Satin Gold

Product Description

The BRASSTECH 517-10-24S is a ceiling mount arm flange designed for overhead shower installations. This component serves as the escutcheon plate and mounting interface where a ceiling-mount shower arm meets the finished ceiling surface. It covers the rough opening and provides a clean, sealed transition between the shower arm pipe and the ceiling finish. The 517-10-24S features a 10-inch profile and is finished in Satin Gold PVD, a physical vapor deposition coating that resists tarnishing and corrosion in wet environments. Licensed plumbers and finish trim installers typically handle this fitting during new construction or renovation projects.

This ceiling mount arm flange is suited for residential and light commercial shower installations where a ceiling-drop shower arm is used. It is intended for overhead shower configurations requiring a finished flange at the ceiling penetration point. The Satin Gold PVD finish coordinates with matching BRASSTECH fixtures and trim in the same finish family. It is appropriate for use in master bath and custom shower applications where exposed hardware finish consistency is required.

Key Features

• 10-inch ceiling mount arm flange profile provides wide coverage at the ceiling penetration
• Satin Gold PVD finish offers durable corrosion and tarnish resistance in wet environments
• Physical vapor deposition coating maintains finish integrity over extended use
• Designed for ceiling-drop shower arm installations in residential and light commercial settings
• Covers rough ceiling opening for a clean, finished appearance at the shower arm entry point

Compatibility

Designed as an OEM-style ceiling mount arm flange for overhead shower arm installations requiring a 10-inch escutcheon in a Satin Gold PVD finish.

Installation Notes

Installation of this flange is typically performed by a licensed plumber during finish trim stage, after rough-in piping is complete and ceiling surfaces are finished. Shut off the water supply to the shower system before working on any connected shower arm components. Ensure the ceiling opening is properly sized and that the shower arm is secure before sliding the flange into position. Follow local plumbing codes, including applicable IPC provisions, for shower arm and trim installation requirements.

Technical Specifications

• Profile Size: 10 inches
• Finish: Satin Gold PVD
• Finish Process: Physical Vapor Deposition (PVD)
• UPC: 091388962820

Standard Information

• Brand: BRASSTECH
• Manufacturer Part Number: 517-10-24S
